Reinforced Concrete Vol. II By Dr. H. J. Shah

1,800.00

By Dr. H. J. Shah

8th Edition 2022
ISBN : 9789385039492
Binding : Paperback
Pages : 776 + 24 = 800
Size (mm) : 279 × 40 × 203
Weight : 1560 g

Download PDF

Compare

Share this product

Description

This book presents the basic principles involved in Analysis and Design of Reinforced Concrete Structures. This Eighth edition of Vol. II has been thoroughly revised and extensively enlarged. Some chapters from Seventh edition were transferred to Vol. I of this book. Now in this Vol. II, it is divided in two parts discuss the followings:

Part I : Multi-storeyed buildings and Part II : Water tanks: Liquid retaining structures.
This is a unique book as it contains material complying with latest Indian codes with their respective amendments till October 2022. All chapters are revised with adding a plenty of new matter, examples and figures.

The outline of the book “Reinforced Concrete Vol. II – Part I : Chapter 01 to 12” as mentioned below:
Chapter 1 Fundamentals of Multi-storeyed buildings and discusses the overall understanding of the subject. Chapter 2 contains an overview of gravity load analysis and design and explains how to calculate gravity loads on beams and columns of the building. Chapter 3 is devoted for basics of building dynamics. Since the buildings are subjected to dynamic loads like wind and earthquake, it becomes necessary to understand some basics of building dynamics. Only a few basics necessary to understand the analysis and design of medium rise buildings are explained. Chapter 4 gives information about lateral loads, viz., wind and earthquake loads. Dynamic nature of wind is not considered in the scope of this book. Therefore, static wind forces are explained and also calculated for buildings, while earthquake forces are only explained. Lateral loads result in lateral deformations of building. Chapter 5 discusses about the deformations (horizontal as well as vertical) in the buildings. Overall deformation and inter-storey drift discussed in this chapter play very important role in design of these buildings. Chapter 6 explains how to calculate earthquake forces on the building as a whole and also component-wise. Response spectrum method is adopted by IS:1893 for earthquake loads calculations. Chapter 7 explains how to plan medium rise buildings to make them earthquake resistant. Chapter 8 discusses the ductile design as per IS:13920 including amendments published so far. It is necessary for all buildings to follow the ductile design (Optional for earthquake zone II).

After getting this preliminary knowledge, an unbraced seven storeyed building (structurally seven storeys) is considered and analyzed; and designed and detailed for all practical considerations manually in chapters 9, 10 and 11. All the chapters are completely based on an excel program. This will clarify the analysis and design of a complete building. Chapter 12 is devoted for walls and shear wall design. Although the building design with shear walls is not considered in the scope of this book. Typically, shear walls are also used for medium rise buildings in modern scenario.

The outline of the book “Reinforced Concrete Vol. II – Part II : Chapter 13 to 20” as mentioned below:
These chapters discuss the design of liquid retaining structures by using limit state theory as was adopted in IS:3370-2009 and also in its 2021 revision. In this respect, it is a unique book.
It starts with fundamentals of liquid retaining structures in Chapter 13 and explains how such structures are different than conventional buildings. Limiting the crack width for no leakage of water from tanks is the key design of such structures. Chapter 14 discusses designs of different members of liquid retaining structures. This chapter should be very helpful to appreciate the design of water tanks. Loads acting on such structures have to be treated in different manner than conventional buildings. Chapter 15 gives good understanding of various loads acting on water tanks.

Complete designs of circular and rectangular tanks resting on ground are treated in chapters 16 and 17 respectively. Since calculation of earthquake loads is yet not known, these chapters assume earthquake loads by using thumb rules recommended by the author. Chapter 18 is devoted for calculating earthquake loads on water tanks which is based on empirical formulae given by IS:1983(Part II). Chapter 19 designs circular and rectangular overhead tanks subjected to all types of loads. Chapter 20 designs an intze tank supported by peripheral columns with full practical details.

Now this book “Reinforced Concreted Vol. II, in its 20 Chapters contains:
* 380 Neatly drawn sketches
* 134 Useful tables
* 109 Design examples
* 209 Questions at the end of chapters
* 066 Examples for practice at the end of chapters.

The book in the present form will prove to be extremely useful to the students preparing for the Degree examinations in Civil Engineering and Architecture of all the Indian Universities, Diploma examinations conducted by various Boards of Technical Education, Certificate Courses as well as for the A.M.I.E., U.P.S.C., G.A.T.E., I.E.S., and other similar competitive and professional examinations. It should also be an immense use to practicing Civil Engineers.

Additional information

Author Name

Book Edition

Valuation of Real Properties By Rangwala

978-93-85039-49-2

Book Binding

Pages

Weight

Old ISBN

, ,

Content

1 : CIRCULAR SLABS
2 : RIBBED SLABS AND WAFFLE SLABS
3 : FLAT SLABS
4 : DOMES
5 : DEEP BEAMS AND CORBELS
6 : BEAMS CURVED IN PLAN
7 : GRID OR COFFERED FLOORS
8 : CIRCULAR RAFT FOUNDATIONS
9 : MULTI-STOREYED BUILDINGS: FUNDAMENTALS
10 : ANALYSIS AND DESIGN FOR GRAVITY LOADS: AN
OVERVIEW
11 : LATERAL LOADS
12 : ANALYSIS FOR LATERAL LOADS
13 : DUCTILITY CONSIDERATIONS
14 : UNBRACED BUILDING DESIGN EXAMPLE – I
15 : UNBRACED BUILDING DESIGN EXAMPLE – II
16 : WALLS IN BUILDINGS
17 : WATER TANKS: FUNDAMENTALS
18 : CIRCULAR TANKS
19 : RECTANGULAR TANKS
20 : ELEVATED WATER TANKS
21 : INTZE TANK
22 : ELEMENTS OF PRESTRESSED CONCRETE
APPENDIX A : SHORT QUESTIONS WITH ANSWERS
APPENDIX B : USEFUL TABLES
INDEX

Details Content

PART I: MULTI-STOREYED BUILDINGS
Chapter 1 Multi-Storyed Buildings:

Fundamentals

1-1. Introduction
1-2. Contributing factors to multi-storeyed buildings
(1)Development of high strength materials
(2)Development of new design concepts
(3)Development of new structural systems
(4)Improved construction methods
(5)Non-destructive testing and
retrofitting techniques
1-3. Nomenclatures
(1)Description of building
(2)Floor number
(3)Storey number
(4)Column number
(5)Main beam number
(6)Floor beam number
1-4. Loads on multi-storeyed buildings
(1)Dead loads
(2)Imposed (live) loads
(3)Wind loads
(4)Earthquake loads
1-5. Primary loads and load combinations
(1)Primary loads
(2)Load combinations
1-6. Shear walls
(1)Isolated shear wall
(2)Coupled shear walls
1-7. Mechanism of load transfer
(1)Gravity loads
(2)Lateral loads
(3)Diaphragm
(4)Linear analysis
DIAPHRAGMS
1-8. Introduction
(1)Foundations
(2)Vertical elements
(3)Horizontal elements
1-9. Diaphragms: functions and types
(1)Flexible diaphragm
(2)Rigid diaphragm
1-10. Forces on diaphragms
(1)In-plane forces
(2)Transfer forces
(3)Connection forces
(4)Column bracing forces
(5)Diaphragm out of plane forces
1-11. Components of diaphragm
(1)Diaphragm slab
(2)Chord elements (tension chord and
compression chord)
(3)Collectors (or distributors)
(4)Connections with vertical elements
1-12. Flat slab and conventional
slab-beam diaphragms
(1)Flat slab diaphragms
(2)Conventional slab/beam diaphragm
1-13. Centre of mass and centre of rigidity
(1)Centre of mass
(2)Centre of rigidity (stiffness)
1-14. Lateral stiffness
(1)Translational stiffness
(2)Rotational stiffness
1-15. Distribution of lateral loads to lateral
force resisting system (LFRS) elements
(1)Flat slab diaphragm
(2)Conventional slab beam diaphragm
(3)Simplification by using relative stiffness – conventional slab beam diaphragm
1-16. Classification of structures
(1)Unbraced structures
(2)Braced structures
(3)Dual structures
1-17. Structural systems
(1)Moment frame systems
(2)Structural wall systems
(3)Dual systems
1-18. Low rise, medium rise, tall and Super tall buildings
1-19. Structural plan density and plan aspect ratio
(1)Structural plan density
(2)Slenderness ratio
(3)Plan aspect ratio
1-20. Structural layout
(1)Building panels
(2)Setting the levels
(3)Setting the columns
(4)Documentation
1-21. Analysis, design and detailing (ADD)
1-22. Distinguishing factors to design of tall buildings
(1)Lateral displacements and drift
(2)Differential shortening of columns
Questions 1

Examples 1

Chapter 2 Analysis And Design For Gravity Loads: An Overview

2-1. Introduction
2-2. Calculation of gravity loads
2-3. Area method
2-4. Beam reaction method
(1)Choice of method
(2)Software calculations
2-5. Imposed load reduction
2-6. Column load calculations
2-7. Gravity load analysis
(1)Substitute frame
(2)Slabs and secondary beams
(3)Main beams
2-8. Important analysis parameters
(1)Modulus of elasticity of reinforced concrete
(2)Effective moment of inertia of
framed members: Stiffness modifiers
2-9. Design of floor
(1)Design for flexure
(2)Corrections in beam moments
(3)Design for shear
2-10. Analysis and design of columns
2-11. Tie beams and ground beams
2-12. Footings
(1)Column/wall — footing connection
(2)Transfer of loads from shallow footings to the soil
(3)Characteristics of soils to be selected for laying foundation
(4)Depth of foundation
(5)Choice of column/wall — footing connection
2-13. Seismic requirements for foundations
2-14. Concreting in slab-beams and columns
2-15. Conclusion

Questions 2

Chapter 3 Basics of Building Dynamics

3-1. Lateral loads
3-2. Basics of vibration
(1)Damping of a system
(2)Classification of vibrations
(3)Types of vibration
3-3. Degrees of freedom
(1)Single degree of freedom (SDOF) system
(2)Multi degree of freedom (MDOF) system
(3)Vibrations in a building (space structure)
(4)Shear building
(5)Practical buildings
